Ranger

Description

The Ranger is ideal for tackling off-road conditions as well as rough tracks.

The Ranger is ideal for tackling off-road conditions as well as rough tracks. Featuring enhanced front and rear suspension, a high ground clearance and a unique range of standard options, the Ranger is perfect for long trips and all day use. Specification
Battery Weight (each) –
Weight Capacity 25 stone (159 kg)
Maximum Speed 8 mph (12.9 km/h)
Ground Clearance 140 mm (5.51″)
Overall Length 1556 mm (61.25″)
Overall Width 829 mm (32.5″)
Turning Radius 2407 mm (94.75″)
Standard Controls –
Heaviest Piece (when disassembled) 15 stone 6lbs (99.25kg)
Total Weight (without batteries) 19 stone 5lbs (124.25 kg)
Suspension Front and rear suspension
Battery Requirements x2 75aH Deep Cycle
Seating Captain’s Seat
Tyres 14.5″ chunky pneumatic tyres
Note 1. Due to manufacturing tolerances and continual product improvement, this specification can be subject to a variance of + or – 3 %. 2. Specification varies with user weight, terrain, battery type, battery condition and tire pressure. 3. Battery weight may vary based on manufacturer. Tested in accordance with ANSI/RESNA, WC Vol. 2, Section 4 and ISO 7176-4 standards. Results derived from theoretical calculations based on battery specifications and drive system performance. Testing conducted at maximum weight capacities. This specification can be subject to a variance of +10%, -5%. The information contained herein is correct at the time of publication; we reserve the right to alter specifications without prior notice. Colours Available: Copper
